Reference for Block Volume

Views

This section provides information about views within Resource Analytics block volume and their columns, data types, keys, and the referred view and column names. The following views are available:

Block Volume Views
View Name	View Description
BLOCK_BACKUP_POLICY_V	This view stores information on policies for automatically creating volume backups according to a recurring schedule. Has a set of one or more schedules that control when and how backups are created.
BLOCK_BOOT_VOLUME_BACKUP_DIM_V	This view stores information on point-in-time copies of a boot volume that can then be used to create a new boot volume or recover a boot volume.
BLOCK_BOOT_VOLUME_DIM_V	This view stores information about the detachable boot volume device that contains the image used to boot a Compute instance.
BLOCK_BOOT_VOLUME_REPLICA_DIM_V	This view stores information about the asynchronous replica of a boot volume that can then be used to create a new boot volume or recover a boot volume.
BLOCK_VOLUME_BACKUP_DIM_V	This view stores information about point-in-time copies of a volume that can then be used to create a new block volume or recover a block volume.
BLOCK_VOLUME_DIM_V	This view stores information about detachable block volume devices that let you dynamically expand the storage capacity of an instance.
BLOCK_VOLUME_GROUP_BACKUP_DIM_V	This view stores information on point-in-time copies of a volume group that can then be used to create a new volume group or restore a volume group.
BLOCK_VOLUME_GROUP_DIM_V	This view stores information on volume groups which are a collection of volumes.
BLOCK_VOLUME_GROUP_REPLICA_DIM_V	This view stores information about asynchronous replicas of a volume group that can then be used to create a new volume group or recover a volume group.
BLOCK_VOLUME_REPLICA_DIM_V	This view stores information about asynchronous replicas of block volumes that can then be used to create a new block volume or recover a block volume.
BLOCK_BACKUP_FACT_V	Fact for block backups. It Includes boot volume backups and volume backups. The measures include backup size.
BLOCK_REPLICA_FACT_V	Fact for block replicas. It includes volume replicas and boot volume replicas. The measures include replica size.
BLOCK_VOLUME_FACT_V	Fact for block volumes. It includes volumes and boot volumes. The measures include volume size, replica count, and backup size/count.
BLOCK_VOLUME_BACKUP_COMBINED_DIM_V	A denormalized view combining the data for block volume backups and boot volume backups. It combines data from BLOCK_VOLUME_DIM_V and BLOCK_BOOT_VOLUME_BACKUP_DIM_V.
BLOCK_VOLUME_COMBINED_DIM_V	A denormalized view combining the data for block volumes and boot volumes. It combines data from BLOCK_VOLUME_DIM_V and BLOCK_BOOT_VOLUME_DIM_V.
BLOCK_VOLUME_REPLICA_COMBINED_DIM_V	A denormalized view combining the data for block volume replicas and boot volume replicas. It combines data from BLOCK_VOLUME_REPLICA_DIM_V and BLOCK_BOOT_VOLUME_REPLICA_DIM_V.

The suffixes in the view names specify the view type:

FACT_V: Fact
DIM_V: Dimension
COMBINED_DIM_V: Denormalized view

Relationship Diagram

This section provides diagrams that define the logical relationship of a fact table with different dimension tables.

The contents of each view and their relationships are listed in the following file: block volume views.

These diagrams show the relationship of the block volume fact view with different dimension views.

BLOCK_BACKUP_FACT_V

BLOCK_REPLICA_FACT_V

BLOCK_VOLUME_FACT_V

Relationships exist among dimensions. Dimensions can be joined directly to each other. These diagrams show the relationship between dimension views.

BLOCK_BACKUP_POLICY_DIM_V

Sample Queries

Sample queries for block volume.

List the tags associated with each block volume:

SELECT TAG_TYPE, TAG_KEY_NAME, TAG_VALUE
FROM OCIRA.TAGS_DIM_V
WHERE RESOURCE_TYPE = 'volume';

List all unattached block volumes:

SELECT BV.ID AS VOLUME_ID, BV.DISPLAY_NAME, BV.SIZE_IN_GBS, BV.COMPARTMENT_ID
FROM OCIRA.BLOCK_VOLUME_DIM_V BV
LEFT JOIN OCIRA.COMPUTE_VOLUME_ATTACHMENT_DIM_V VA
ON BV.ID = VA.VOLUME_ID
WHERE VA.VOLUME_ID IS NULL;

List the all block volumes with attachments:

SELECT V.ID AS VOLUME_ID, V.DISPLAY_NAME, V.SIZE_IN_GBS, V.COMPARTMENT_ID, VA.ATTACHMENT_TYPE, VA.INSTANCE_ID
FROM OCIRA.BLOCK_VOLUME_DIM_V V
LEFT JOIN OCIRA.COMPUTE_VOLUME_ATTACHMENT_DIM_V VA
ON V.ID = VA.VOLUME_ID
WHERE VA.LIFECYCLE_STATE = 'Attached';

List the size of all volumes in a specific compartment:

SELECT ENTITY_TYPE, VOLUME_ENTITY_ID, SIZE_IN_GBS
FROM OCIRA.BLOCK_VOLUME_FACT_V
WHERE COMPARTMENT_ID = '<insert compartment ID>';

List the details of all block and boot volume backups:

SELECT VOLUME_ID, ID, DISPLAY_NAME, LIFECYCLE_STATE, SIZE_IN_GBS, TIME_CREATED, EXPIRATION_TIME
FROM OCIRA.BLOCK_VOLUME_BACKUP_COMBINED_DIM_V;

Data Lineage

The Customer Experience Semantic Model Lineage spreadsheet and Metric Calculation Logic spreadsheet for block volume provides an end-to-end data lineage summary report for physical and logical relationships in your data.

For more information, see Data Lineage.

Subject Areas

This section provides information on the subject areas with data you maintain in network Block Volume. These subject areas, with their corresponding data, are available for you to use when creating and editing analyses and reports. The information for each subject area includes:

Description of the subject area.
Business questions that can be answered by data in the subject area, with a link to more detailed information about each business question.
Job-specific groups and duty roles that can be used to secure access to the subject area, with a link to more detailed information about each job role and duty role.
Primary navigation to the work area that's represented by the subject area.
Time reporting considerations in using the subject area, such as whether the subject area reports historical data or only the current data. Historical reporting refers to reporting on historical transactional data in a subject area. With a few exceptions, all dimensional data are current as of the primary transaction dates or system date.
The lowest grain of transactional data in a subject area. The lowest transactional data grain decides how data are joined in a report.
Special considerations, tips, and things to look out for in using the subject area to create analyses and reports.

The subject areas are:

Other References

This section provides other references related to block volume.

Oracle Cloud Infrastructure Documentation
